Expand Your Opportunities with Direct-to-Object Printing
VersaOBJECTNEW CO-i Series Flatbed UV Printers
-
MSRP
CO-300i-F2
$49,995 US*
(60-in length, with vacuum)CO-640i-F3
$74,995 US*
(98-in length, with vacuum)* U.S. only. For Canada, Latin America and Caribbean pricing, please contact an Authorized Roland DGA Dealer in your area.
-
LEASE PRICE
$1,015 US**
$1,522 US**** For 60 months, OAC
Take object customization to new heights with the VersaOBJECT CO-i series of UV flatbed printers. Digital UV printing has never been more versatile and the CO-i series is the perfect solution for customizing boards or objects up to 9.5 inches (242 mm) in height and even irregular 3D objects.
- Premium-quality direct-to-object or substrate printing
- Special effect printing for added-value products
- High-volume object customization and personalization
- Available in a size and configuration to suit your business
- New integrated control panel
Flatbed UV Printing Solutions
CO-640i
CO-300i
The Ultimate in Versatile Print Production
Print high-quality, vibrant, impactful graphics directly onto a vast range of materials and objects, including metal, plastic, board, wood, canvas, vinyl, paper, and much more. Plus, CO-i series flatbeds can accommodate items up to 9.5 inches in height.
Everything You Need to Succeed
Choose from 2 different models and sizes to suit your business.
Power your workflow with our most intelligent engine yet.
Get stunning results every time with economical ECO-UV5 ink.
Secure your investment with industry-leading support.
High Quality, Versatile Ink
Using the latest ECO-UV EUV5 inks for exceptional and premium-value printing, we go beyond CMYK to give you even more options and flexibility. Talk to a Roland DG product expert about your print requirements to discover the ink configuration that’s right for you.
CMYK
Get premium results with high-quality CMYK EUV5 ink.
Gloss
Generate a multitude of tangible effects, simulated embossing, and gloss finishes.
White
Print high-opacity white details or add sub-coats for dark or transparent materials.
Red and Orange
With our True Rich Color preset, extend your available gamut and reproduce brand colors perfectly.
Primer
Apply primer to the print area with precision for extensive media compatibility.
Certifications
GREENGUARD Gold
ECO-UV5 inks are GREENGUARD Gold certified, meaning they meet strict standards of low chemical emissions making them ideal for indoor applications.
Key Benefits
|
Broad Substrate Compatibility Print onto a virtually limitless range of flexible and rigid substrates and objects. |
|
Printing Distance Mode Print directly onto irregular or curved objects with a high degree of accuracy. |
|
Powerful Software Included Included VersaWorks 6 RIP software provides a host of workflow efficiency tools, advanced color management features, printable texture libraries, and much more. |
|
Time Saving Turnaround Switch to digital direct-to-object printing and eliminate long set-up and finishing times. |
|
The Roland DG Legacy Make a safe investment with Roland DG’s world-renowned quality and reliability. |
|
Low Running Cost Long-life printheads and ink-clogging prevention features extend product life and ensure sustained quality. |
|
Fast Set-up and Ease of Use Plug in and start working immediately thanks to Roland DG’s user-friendly interface. |
|
Mobile Cost Tracking Track ink usage and more in real time with the Roland DG Connect mobile app. |
Highlighted Features
Impressive Height and Weight Capabilities
Offering extraordinary application versatility, the CO-i series flatbeds can print on objects up to 9.5 inches in height and weighing up to 100 kg/m2 in weight.
New Integrated Control Panel
The control panel of the CO-i Series is integrated into the table to allow you to work more efficiently in less space. The more efficient design removes the conjoining cable trip hazard, reducing the possibility of damaging the device and increasing safety.
Print Large Quantities of Smaller Items
Improve your productivity with a fast and efficient direct-to-object printing solution. The CO-i series lets you print unique details on several items in a single print run. Plus, with VersaWorks 6 features like variable data printing, you can individually personalize each item quickly with minimal set-up.
Distance Mode
The CO-i series flatbed UV printers feature an innovative Distance Mode. This makes it possible to print onto convex, concave, or irregular surfaces while maintaining excellent quality and sharpness.
Low-Temperature Adjustable UV-LED Lamps
Intensity of the UV-LED lamps is adjustable from VersaWorks – they can be switched on, off, or set anywhere in between. This allows Gloss, Primer, and White to be used as an adhesive layer before a secondary process to apply glitter or foil, and then cured with UV to seal.
Safety Control Features
An emergency stop perimeter around base (and on the side of the device) safeguards operators in the busiest of production environments. For additional safety, there is a signal beacon with variable alerts that clearly highlights the printer status.
Powerful Software Included
The VersaOBJECT CO-i series is even more powerful when paired with Roland DG's advanced software solutions. Developed specifically for Roland DG, our easy-to-use, feature-filled software gives you all you need to produce your work, your way.
VersaWorks 6 RIP Software
Besides its high-speed RIP functionality, VersaWorks 6 RIP includes a wide selection of productivity-boosting features for the CO-i series, like automatic special color generation and variable data printing.
LEARN MORE
Roland DG Connect App
Reduce downtime and improve work efficiency with a machine monitoring assistant that gives you a clear picture of your print operation while running your device at optimum performance.
LEARN MORE
PrintAutoMate
This specialized software, an optional expansion to the Roland DG Connect app, lets you efficiently map print output onto objects in a printing jig, helping you automate your print workflow and streamline object customization.
LEARN MORE
Create Value with Direct Printing
Introducing VersaOBJECT from Roland DG - a comprehensive solution that enables anyone to easily print directly onto 3D objects made of a variety of materials.
Protect Your Investment
Take your business forward with complete peace of mind thanks to Roland DG’s renowned post-sale service. Roland DG Care warranties cover you for much more than device maintenance.*
- Factory-trained service engineers
- Quick installation and first-time set-up
- Expert advice and training
* Registration within 60 days of purchase and exclusive, continuous use of Roland DG approved inks is required to qualify for the second year of warranty coverage.
Additional Information
Datasheet
Download Your CO-i Series Datasheet
Get your digital guide to all the features, applications, benefits and specifications of the UV Printers.
Download DatasheetSpecifications
| Model | CO-300i-F2 | CO-640i-F3 | |||
| Printing Method | Piezo ink-jet method | ||||
| Attachable objects to be printed on | Width | Max. 30 in. (762 mm ) |
Max. 64 in. (1,625 mm) |
||
| Thickness | Max. 9.5 in. (242 mm) | ||||
| Weight | Max. 220.4 Ib (100 kg) |
||||
| Maximum Printing Width/Length | Max. 29.4 in. × 59.0 in. (749 × 1,500 mm) |
Max. 63.4 in. × 98.4 in. (1,612 × 2,500 mm) |
|||
| Ink |
Types | ECO-UV（EUV5） 220 ml cartridge（White） ECO-UV（EUV5） 500 ml cartridge（Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer） |
|||
| Colors |
Eight colors (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss) Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White） Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer Seven colors (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer Six colors (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer Six colors (Cyan, Magenta, Yellow, Black, White, Gloss） Four colors (Cyan, Magenta, Yellow, Black) |
||||
| Ink-curing unit | Built-in UV-LED lamp | ||||
| Printing resolution (dots per inch) | Max. 1,440 dpi | ||||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||||
| Power-saving Function | Automatic sleep feature | ||||
| Power Requirements | 230V 16A 2P+E | ||||
| Power Consumption | During operation (100% Vacuum) | Approx. 1.80 kW | Approx. 2.90 kW | ||
| Sleep mode | Approx. 0.08 kW | ||||
| Acoustic Noise Level | During operation | 80 dB (A) or less | 90 dB (A) or less | ||
| During Standby | 70 dB (A) or less | 80 dB (A) or less | |||
| Dimensions (width x depth x height) | 76.0 in. × 93.9 in. × 57.9 in. (1,928 mm × 2,384 mm × 1,469 mm) |
110.9 in. × 133.9 in. × 57.9 in. (2,815 mm × 3,399 mm × 1,469 mm) |
|||
| Weight | 1,074 lb. (487 kg) | 1,903 lb. (863 kg) | |||
| Environment | During operation(*1) | Temperature: 68 to 89.6 °F (20 to 32 °C), Humidity: 35 to 80 %RH (no condensation) |
|||
| Not operating | Temperature: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 %RH (no condensation) |
||||
| Included Items | Power cord, cleaning liquid, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc. | ||||
