VersaOBJECT CO-i Series Flatbed UV Printers | Roland DGA
VersaOBJECT COi Series UV Flatbed Printer
VersaOBJECT logo

Expand Your Opportunities with Direct-to-Object Printing

VersaOBJECTNEW CO-i Series Flatbed UV Printers

  • MSRP

    CO-300i-F2
    $49,995 US*
    (60-in length, with vacuum)

    CO-640i-F3
    $74,995 US*
    (98-in length, with vacuum) Limited time only + $4,995 Savings with MG-640 Combo

    Get Promo

    * Promotion valid through 12/23/2024. See promo page for terms and conditions.

  • LEASE PRICE

    CO-300i-F2
    $1,015 US**

    CO-640i-F3
    $1,522 US**

    ** For 60 months, OAC

Take object customization to new heights with the VersaOBJECT CO-i series of UV flatbed printers. Digital UV printing has never been more versatile and the CO-i series is the perfect solution for customizing boards or objects up to 9.5 inches (242 mm) in height and even irregular 3D objects.

  • Premium-quality direct-to-object or substrate printing
  • Special effect printing for added-value products
  • High-volume object customization and personalization
  • Available in a size and configuration to suit your business
  • New integrated control panel

Flatbed UV Printing Solutions

VersaOBJECT CO-640i UV printer top view

CO-640i

Flatbed UV Printer
Printable Width
63 inches
Printable Length Options
98 inches
Max. Print Height
9.5 inches
Bed Options
Flatbed with Vacuum
Available ink
CMYK, Gloss, White, Red, Orange, Primer
VersaOBJECT CO-300i UV printer top view

CO-300i

Flatbed UV Printer
Printable Width
30 inches
Printable Length Options
60 inches
Max. Print Height
9.5 inches
Bed Options
Flatbed with Vacuum
Available ink
CMYK, Gloss, White, Red, Orange, Primer

The Ultimate in Versatile Print Production

Print high-quality, vibrant, impactful graphics directly onto a vast range of materials and objects, including metal, plastic, board, wood, canvas, vinyl, paper, and much more. Plus, CO-i series flatbeds can accommodate items up to 9.5 inches in height.

versaobjectcogenerator
Custom Coffee Tray
versaobjectcobottle
versaobjectcophonecases
versaobjectcowallart
Packaging Prototype

Everything You Need to Succeed

CO-i Series Flatbed UV Printer

Choose from 2 different models and sizes to suit your business.

VersaWorks 6 RIP

VersaWorks 6 RIP

Power your workflow with our most intelligent engine yet.

Premium EUV Ink

Premium EUV5 Ink

Get stunning results every time with economical ECO-UV5 ink.

Roland DG Care Warranty

Roland DG Care Warranty

Secure your investment with industry-leading support.

High Quality, Versatile Ink

Using the latest ECO-UV EUV5 inks for exceptional and premium-value printing, we go beyond CMYK to give you even more options and flexibility. Talk to a Roland DG product expert about your print requirements to discover the ink configuration that’s right for you.



CMYK

Get premium results with high-quality CMYK EUV5 ink.

Gloss

Generate a multitude of tangible effects, simulated embossing, and gloss finishes.

White

Print high-opacity white details or add sub-coats for dark or transparent materials.

Red and Orange

With our True Rich Color preset, extend your available gamut and reproduce brand colors perfectly.

Primer

Apply primer to the print area with precision for extensive media compatibility.

Certifications

GREENGUARD Certified

GREENGUARD Gold

ECO-UV5 inks are GREENGUARD Gold certified, meaning they meet strict standards of low chemical emissions making them ideal for indoor applications.

Key Benefits

Broad Substrate Compatibility
Print onto a virtually limitless range of flexible and rigid substrates and objects.
Printing Distance Mode
Print directly onto irregular or curved objects with a high degree of accuracy.
VersaWorks Powerful Software Included
Included VersaWorks 6 RIP software provides a host of workflow efficiency tools, advanced color management features, printable texture libraries, and much more.
Time Saving Turnaround
Switch to digital direct-to-object printing and eliminate long set-up and finishing times.
Roland DG Legacy The Roland DG Legacy
Make a safe investment with Roland DG’s world-renowned quality and reliability.
Low Running Cost
Long-life printheads and ink-clogging prevention features extend product life and ensure sustained quality.
Fast Set-up and Ease of Use
Plug in and start working immediately thanks to Roland DG’s user-friendly interface.
Mobile Cost Tracking
Track ink usage and more in real time with the Roland DG Connect mobile app.

Highlighted Features

Impressive Height and Weight Capabilities

Offering extraordinary application versatility, the CO-i series flatbeds can print on objects up to 9.5 inches in height and weighing up to 100 kg/m2 in weight.

New Integrated Control Panel

The control panel of the CO-i Series is integrated into the table to allow you to work more efficiently in less space. The more efficient design removes the conjoining cable trip hazard, reducing the possibility of damaging the device and increasing safety.

Print Large Quantities of Smaller Items

Improve your productivity with a fast and efficient direct-to-object printing solution. The CO-i series lets you print unique details on several items in a single print run. Plus, with VersaWorks 6 features like variable data printing, you can individually personalize each item quickly with minimal set-up.

Distance Mode

The CO-i series flatbed UV printers feature an innovative Distance Mode. This makes it possible to print onto convex, concave, or irregular surfaces while maintaining excellent quality and sharpness.

Low-Temperature Adjustable UV-LED Lamps

Intensity of the UV-LED lamps is adjustable from VersaWorks – they can be switched on, off, or set anywhere in between. This allows Gloss, Primer, and White to be used as an adhesive layer before a secondary process to apply glitter or foil, and then cured with UV to seal.

Safety Control Features

An emergency stop perimeter around base (and on the side of the device) safeguards operators in the busiest of production environments. For additional safety, there is a signal beacon with variable alerts that clearly highlights the printer status.

Powerful Software Included

The VersaOBJECT CO-i series is even more powerful when paired with Roland DG's advanced software solutions. Developed specifically for Roland DG, our easy-to-use, feature-filled software gives you all you need to produce your work, your way.

VersaObject
VersaObject

Create Value with Direct Printing

Introducing VersaOBJECT from Roland DG - a comprehensive solution that enables anyone to easily print directly onto 3D objects made of a variety of materials.

FIND OUT MORE

2 Year Trouble Free Warranty Logo
2 Year Trouble Free Warranty Logo

Protect Your Investment

Take your business forward with complete peace of mind thanks to Roland DG’s renowned post-sale service. Roland DG Care warranties cover you for much more than device maintenance.*

  • Factory-trained service engineers
  • Quick installation and first-time set-up
  • Expert advice and training

* Registration within 60 days of purchase and exclusive, continuous use of Roland DG approved inks is required to qualify for the second year of warranty coverage.

Additional Information

Expand All | Collapse All

Download Your CO-i Series Datasheet

Get your digital guide to all the features, applications, benefits and specifications of the UV Printers.

Download Datasheet


Model CO-300i-F2 CO-640i-F3
Printing Method Piezo ink-jet method
Attachable objects to be printed on Width Max. 30 in.
(762 mm )
Max. 64 in.
(1,625 mm)
Thickness Max. 9.5 in. (242 mm)
Weight Max. 220.4 Ib
(100 kg)
Maximum Printing Width/Length Max. 29.4 in. × 59.0 in.
(749 × 1,500 mm)
Max. 63.4 in. × 98.4 in.
(1,612 × 2,500 mm)
Ink
Types ECO-UV(EUV5) 220 ml cartridge(White)
ECO-UV(EUV5) 500 ml cartridge(Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer)
Colors Eight colors (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss)
Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White)
Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer
Seven colors (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer
Six colors (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer
Six colors (Cyan, Magenta, Yellow, Black, White, Gloss)
Four colors (Cyan, Magenta, Yellow, Black)
Ink-curing unit Built-in UV-LED lamp
Printing resolution (dots per inch) Max. 1,440 dpi
Connectivity Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving Function Automatic sleep feature
Power Requirements 230V 16A 2P+E
Power Consumption During operation (100% Vacuum) Approx. 1.80 kW Approx. 2.90 kW
Sleep mode Approx. 0.08 kW
Acoustic Noise Level During operation 80 dB (A) or less 90 dB (A) or less
During Standby 70 dB (A) or less 80 dB (A) or less
Dimensions (width x depth x height) 76.0 in. × 93.9 in. × 57.9 in.
(1,928 mm × 2,384 mm × 1,469 mm)
110.9 in. × 133.9 in. × 57.9 in.
(2,815 mm × 3,399 mm × 1,469 mm)
Weight 1,074 lb. (487 kg) 1,903 lb. (863 kg)
Environment During operation(*1) Temperature: 68 to 89.6 °F (20 to 32 °C),
Humidity: 35 to 80 %RH (no condensation)
Not operating Temperature: 41 to 104 °F (5 to 40 °C),
Humidity: 20 to 80 %RH (no condensation)
Included Items Power cord, cleaning liquid, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc.
1 Operating environment (Use the machine in an operating environment within these ranges.)
